Model FD-E10HP with max pressure 21MPa and output 2–9 kg/min.
FD-E10HP (Electric) — High-Pressure 1:1 Spray Foam Machine
The FD-E10HP electric spray foam machine is a compact, heavy-duty solution engineered for
contractors who need reliable, high-pressure 1:1 proportioning for polyurethane spray foam
and other two-component materials. Designed for continuous operation with powerful heaters
and long heated hose capability, the FD-E10HP delivers consistent output and stable material
temperatures for better foam quality and faster jobsites.
Key Benefits
- Stable 1:1 fixed ratio for accurate mixing and consistent foam performance.
- Wide material viscosity tolerance (200–1000 CPS at working temperature) for versatility.
- High working pressure up to 21 MPa (210 bar) for long hose runs and consistent spray.
- Dual 3000 W heaters and up to 60 m heated hose support reliable temperature control.
- Compact footprint and robust 150 kg construction for transport and jobsite durability.
Typical Applications
Ideal for residential and commercial insulation, roofing, cavity fill, protective coatings,
and other applications that require professional two-component spray equipment.
Technical Specifications
| Model | FD-E10HP (Electric) |
|---|---|
| Data ratio of raw materials | 1 : 1 (FIXED) |
| Raw material viscosity range | 200–1000 CPS (at working temperature) |
| Max working pressure | 21 MPa (210 bar) |
| Maximum fluid temperature | 0–88 °C (190 °F) |
| Maximum output | 2–9 kg/min |
| Max heated hose length | 60 meters |
| Each heater power | 3000 W × 2 |
| Whole power | 11 kW |
| Voltage | 110V/220V 1-phase • 220V 3-phase • 380V 3-phase |
| Air source supply | ≥ 0.1 m³/min (without using transfer pump) |
| Machine size (L×W×H) | 705 × 916 × 1166 mm |
| Gross weight | 150 kg |
Notes & Ordering
Prices shown are indicative. Contact us for shipping options, lead times, and any required
customization or accessories (transfer pumps, spray guns, reels, fittings, etc.). For safe
operation always follow the manufacturer’s recommendations for material handling and PPE.
| Model |
FD-E10HP |
|---|---|
| Pressure |
21MPa |
| Output |
2–9 kg/min |
| Voltage |
110/220V 1-phase |
| Weight |
150kg |
| Standard Configuration | Quantity |
|---|---|
| Mainframe | 1 set |
| Spray gun (P2) | 1 set |
| Transfer pump | 2 sets (E10HP not included) |
| Heated hose | 15 m (49.2 ft) |
| Supply hose (From the transfer pump to the machine) |
2 pcs (1.5 meters) |
| Whip hose | 1 pcs |
| Air pipe | 1 set |
| Tools and spare parts | 1 set |
