Model FD-411A with max pressure 17MPa and output 2–9 kg/min.
FD-411A (Pneumatic) — Two-Component Spray Machine
The FD-411A is a heavy-duty pneumatic 1:1 two-component spray machine designed for consistent, high-pressure
delivery of polyurethane and other 2-component materials. Engineered for reliability and easy integration on job sites,
the FD-411A delivers stable proportioning, long heated hose capability, and multiple voltage options to suit your setup.
Key Benefits
- Fixed 1:1 ratio ensures accurate proportioning for consistent material performance.
- High working pressure (up to 17 MPa / 170 bar) for improved spraying distance and atomization.
- Long heated hose support (standard 45 m, customizable up to 60 m) for remote spraying flexibility.
- Robust output range (2–9 kg/min) to suit small-to-medium jobs while maintaining control.
- Multiple power/voltage options and compact footprint for easy transport and on-site use.
Technical Specifications
| Model | FD-411A (Pneumatic) |
|---|---|
| Mix Ratio | 1 : 1 (fixed) |
| Raw Material Viscosity Range | 200 – 1000 CPS (at working temperature) |
| Max Working Pressure | 17 MPa (170 bar) |
| Maximum Fluid Temperature | 0 – 88 °C (up to 190 °F) |
| Maximum Output | 2 – 9 kg/min |
| Max Heated Hose Length | Standard 45 m (customizable up to 60 m) |
| Heater Power (each) | 3000 W × 2 |
| Total Power | 8 kW |
| Voltage Options | 110 V / 220 V (single phase) or 220 V / 380 V (three phase) |
| Air Supply | 0.9 m³/min |
| Machine Size (L×W×H) | 620 × 610 × 1162 mm |
| Gross Weight | Approx. 230 kg |
Applications & Use Cases
Ideal for spray foam insulation, coatings and other 2-component applications where controlled proportioning, pressure,
and heated hose delivery are required. Frequently used in building insulation, refrigerated truck lining, and specialty
coating projects.
Note: Specifications and price are indicative. Contact the supplier for final configuration options,
shipping, customization (heated hose length), and electrical compatibility for your region.
| Model |
FD-411A |
|---|---|
| Pressure |
17MPa |
| Output |
2–9 kg/min |
| Voltage |
110/220V 1-phase |
| Weight |
230kg |
| Standard Configuration | Quantity |
|---|---|
| Mainframe | 1 set |
| Spray gun (P2) | 1 set |
| Transfer pump | 2 sets |
| Heated hose | 15 m (49.2 ft) |
| Supply hose (From the transfer pump to the machine) |
2 pcs (1.5 meters) |
| Whip hose | 1 pcs |
| Air pipe | 1 set |
| Tools and spare parts | 1 set |
| English user manual | 1 set |
